Front wiper/washer circuit, hatchback for Honda Civic VII facelift (2003-2006)
Front wiper/washer circuit, hatchback
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FR WASHER (INT)
FUSE 20 WPR
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START
MIST WIPER INPUT FR WIPER PASS
MULTIPLEX CONTROL UNIT FR WASHER MOTOR
RED WIRE
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
WHT WIRE
WINDSHIELD WASHER MOTOR (BEHIND LEFT SIDE OF FRONT BUMPER)
WINDSHIELD WIPER MOTOR 1 PARK 2 RUN 3 LOW 4 HIGH (UNDER LEFT SIDE OF COWL COVER)
WIPER/ WASHER SWITCH 0 OFF 1 INTERMITTENT 2 LOW 3 HIGH 4 MIST 5 WASH
YEL WIRE
