Power mirrors circuit, without defogger hybrid for Honda Civic VII facelift (2003-2006)
Power mirrors circuit, without defogger hybrid
BLK WIRE
BLK/YEL WIRE
BLU WIRE
FUSE 14
GRN WIRE
HOT IN ON
LEFT POWER MIRROR
LEFT UP RIGHT DOWN
LEFT/ RIGHT MOTOR
LEFT/ RIGHT MOTOR UP/ DOWN MOTOR
POWER MIRROR SWITCH
POWER MIRROR SWITCH LIGHT
RED WIRE
RIGHT DOWN LEFT UP
RIGHT LEFT
RIGHT POWER MIRROR
RIGHT UP LEFT DOWN SWITCH 2
SWITCH 1
SWITCH 3
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
