Power mirrors circuit, without defogger except hatchback & hybrid for Honda Civic VII facelift (2003-2006)
Power mirrors circuit, without defogger except hatchback & hybrid
BLK WIRE
BLK/YEL WIRE
BLU WIRE
GRN WIRE
HOT IN ON FUSE 14
LEFT POWER MIRROR
LEFT UP RIGHT DOWN
LEFT/ RIGHT MOTOR
POWER MIRROR SWITCH
RED WIRE
RIGHT DOWN LEFT UP
RIGHT LEFT
RIGHT POWER MIRROR
RIGHT UP LEFT DOWN SWITCH 2
SWITCH 1 POWER MIRROR SWITCH LIGHT
SWITCH 3
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
