Back-up lamps circuit, hybrid for Honda Civic VII facelift (2003-2006)
Back-up lamps circuit, hybrid
A/T REVERSE RELAY (BEHIND GLOVE BOX)
BACK-UP LIGHT SWITCH (ON TRANSAXLE HOUSING)
BLK WIRE
CVT
ECM (BEHIND GLOVE BOX)
FUSE 10
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN ON OR START
JUNCTION
JUNCTION CONNECTOR
LEFT BACK-UP LIGHT
M/T
RED/WHT WIRE
RIGHT BACK-UP LIGHT
TCM (BEHIND RIGHT KICK PANEL)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE HOUSING)
UNDERDASH FUSE/RELAY BOX
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
