Cooling fan circuit, hatchback for Honda Civic VII facelift (2003-2006)
Cooling fan circuit, hatchback
A/C CLUTCH
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C COMPRESSOR THERMAL PROTECTOR
A/C CONDENSER FAN MOTOR (FORWARD OF RADIATOR)
A/C ON
A/C PRESSURE SWITCH (BEHIND LEFT SIDE OF A/C CONDENSER FAN)
ACS
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CONDENSER FAN RELAY
ECM/PCM (BEHIND GLOVE BOX)
FUSE 1
FUSE 14
FUSE 4
GRN WIRE
GRN/WHT WIRE
HEATER CONTROL PANEL
HOT AT ALL TIMES
HOT IN ON
NCA WIRE
RADIATOR FAN MOTOR (BEHIND RADIATOR)
RADIATOR FAN RELAY
RADIATOR FAN SWITCH (MIDDLE OF ENGINE)
RED WIRE
SEFMJ
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
