Immobilizer circuit, hybrid for Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE CARLINK CARLINK IINTERFACE BOX (UNDER MIDDLE OF DASH) COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM ECM (BEHIND GLOVE BOX) ENGINE CONTROLS SYSTEM FUEL TANK UNIT (ON TOP OF FUEL TANK) FUEL PUMP FUSE 17 FUSE 4 FUSE 6 FUSE 9 GAUGE ASSEMBLY GRN/ORG WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBI- LIZER CORD IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER) IMMOBILIZER SYSTEM INDICATOR IMO FPR INSTRUMENT CLUSTER SYSTEM JUNCTION MRLY MULTI-FUSE/ RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) MULTIPLEX CONTROL UNIT PGM-FI MAIN RELAY 1 (BEHIND GLOVE BOX) PGM-FI MAIN RELAY 2 RED WIRE RED/BLU WIRE RED/YEL WIRE UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/ RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
