Honda Civic VII facelift (2003-2006) Anti-lock brakes circuit, hybrid

ABS INDICATOR ABS INDICATOR CIRCUIT ABS MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT) BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH) BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EBD FUSE 10 FUSE 11 FUSE 7 FUSE 10 FUSE 8 GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GROUND GROUND GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL) LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL) LT GRN/RED WIRE MCM (BEHIND GLOVE BOX) MULTIPLEX CONTROL UNIT ORG/ WIRE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL) RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL) UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
