Honda Civic VII facelift (2003-2006) w/o accessory installed w/ accessory installed wiring diagram
This page shows the only wiring diagram for the component.w/o accessory installed w/ accessory installed, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/o accessory installed w/ accessory installed wiring diagram (1 of 1)
A/F SENSOR RELAY (HX, DX, EX, LX)
BLOWER MOTOR RELAY
CANADA
DRL CONTROL UNIT
EXCEPT DX
FROM UNDERHOOD FUSE/RELAY BOX
FUSE 11 (SEDAN) (COUPE)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 5 (NOT USED)
FUSE 7
GRN WIRE
HATCHBACK
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
MOONROOF CLOSE RELAY MOONROOF OPEN RELAY
MULTIPLEX CONTROL UNIT
POWER WINDOW RELAY
REAR WINDOW DEFOGGER RELAY
RED/BLU WIRE
SECURITY CONTROL UNIT
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
W/O ACCESSORY INSTALLED W/ ACCESSORY INSTALLED
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 4) -> W/O ACCESSORY INSTALLED W/ ACCESSORY INSTALLED
