Honda Civic VII facelift (2003-2006) switch 1 power mirror switch light Wiring diagram
This page shows the only wiring diagram for the component.switch 1 power mirror switch light, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch 1 power mirror switch light (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
GRN WIRE
HOT IN ON FUSE 14
LEFT POWER MIRROR
LEFT UP RIGHT DOWN
LEFT/ RIGHT MOTOR
POWER MIRROR SWITCH
RED WIRE
RIGHT DOWN LEFT UP
RIGHT LEFT
RIGHT POWER MIRROR
RIGHT UP LEFT DOWN SWITCH 2
SWITCH 1 POWER MIRROR SWITCH LIGHT
SWITCH 3
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit, without defogger except hatchback & hybrid -> SWITCH 1 POWER MIRROR SWITCH LIGHT
