Honda Civic VII facelift (2003-2006) right left Wiring diagrams

This page contains all the electrical diagrams for the component. right left, in which he is found in the car Honda Civic VII facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right left (1 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (1 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/YEL WIRE BLU WIRE DEFOGGER DEFOGGER SWITCH GRN WIRE HOT IN ON FUSE 14 LEFT LEFT POWER MIRROR LEFT UP RIGHT DOWN SWITCH 3 LEFT/ RIGHT MOTOR UP/ DOWN MOTOR ORG/ WIRE POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RIGHT RIGHT DOWN LEFT UP RIGHT UP LEFT DN SWITCH 2 SWITCH 1 RIGHT LEFT RIGHT POWER MIRROR UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit, with defogger except hatchback & hybrid -> RIGHT LEFT

Wiring diagram right left (2 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (2 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE DEFOGGER DEFOGGER SWITCH FUSE 14 GRN WIRE GRN/WHT WIRE GRY WIRE HOT IN ON LEFT LEFT POWER MIRROR LEFT/ RIGHT MOTOR UP/ DOWN MOTOR LT GRN WIRE ORG/ WIRE PNK WIRE POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RED/YEL WIRE RIGHT RIGHT LEFT RIGHT POWER MIRROR UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE YEL/WHT WIRE

Go to component -> Power mirrors circuit, with defogger hatchback -> RIGHT LEFT

Wiring diagram right left (3 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (3 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/YEL WIRE BLU WIRE DEFOGGER DEFOGGER SWITCH FUSE 14 GRN WIRE HOT IN ON LEFT LEFT POWER MIRROR LEFT UP RIGHT DN SWITCH 3 LEFT/ RIGHT MOTOR UP/ DOWN MOTOR ORG/ WIRE POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RIGHT RIGHT DN LEFT UP RIGHT UP LEFT DN SWITCH 1 SWITCH 2 RIGHT LEFT RIGHT POWER MIRROR UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit, with defogger hybrid -> RIGHT LEFT

Wiring diagram right left (4 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (4 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/YEL WIRE BLU WIRE GRN WIRE HOT IN ON FUSE 14 LEFT POWER MIRROR LEFT UP RIGHT DOWN LEFT/ RIGHT MOTOR POWER MIRROR SWITCH RED WIRE RIGHT DOWN LEFT UP RIGHT LEFT RIGHT POWER MIRROR RIGHT UP LEFT DOWN SWITCH 2 SWITCH 1 POWER MIRROR SWITCH LIGHT SWITCH 3 UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UP/ DOWN MOTOR WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit, without defogger except hatchback & hybrid -> RIGHT LEFT

Wiring diagram right left (5 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (5 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE FUSE 14 GRN WIRE GRN/WHT WIRE GRY WIRE HOT IN ON LEFT LEFT POWER MIRROR LEFT/ RIGHT MOTOR UP/ DOWN MOTOR LT GRN WIRE ORG/ WIRE PNK WIRE POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RED/YEL WIRE RIGHT RIGHT LEFT RIGHT POWER MIRROR UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit, without defogger hatchback -> RIGHT LEFT

Wiring diagram right left (6 of 6)

Wiring diagram right left for Honda Civic VII facelift (2003-2006) (6 of 6)

Get lifetime access to Honda Civic VII facelift (2003-2006)

BLK WIRE BLK/YEL WIRE BLU WIRE FUSE 14 GRN WIRE HOT IN ON LEFT POWER MIRROR LEFT UP RIGHT DOWN LEFT/ RIGHT MOTOR LEFT/ RIGHT MOTOR UP/ DOWN MOTOR POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RIGHT DOWN LEFT UP RIGHT LEFT RIGHT POWER MIRROR RIGHT UP LEFT DOWN SWITCH 2 SWITCH 1 SWITCH 3 UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UP/ DOWN MOTOR WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit, without defogger hybrid -> RIGHT LEFT

Honda Civic VII facelift (2003-2006) right left Wiring diagrams

Wiring diagram right left (1 of 6)

List of components:

Wiring diagram right left (2 of 6)

List of components:

Wiring diagram right left (3 of 6)

List of components:

Wiring diagram right left (4 of 6)

List of components:

Wiring diagram right left (5 of 6)

List of components:

Wiring diagram right left (6 of 6)

List of components:
