Honda Civic VII facelift (2003-2006) right dn left up right up left dn switch 1 switch 2 Wiring diagram
This page shows the only wiring diagram for the component.right dn left up right up left dn switch 1 switch 2, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right dn left up right up left dn switch 1 switch 2 (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
DEFOGGER
DEFOGGER SWITCH
FUSE 14
GRN WIRE
HOT IN ON
LEFT
LEFT POWER MIRROR
LEFT UP RIGHT DN SWITCH 3
LEFT/ RIGHT MOTOR UP/ DOWN MOTOR
ORG/ WIRE
POWER MIRROR SWITCH
POWER MIRROR SWITCH LIGHT
RED WIRE
RIGHT
RIGHT DN LEFT UP RIGHT UP LEFT DN SWITCH 1 SWITCH 2
RIGHT LEFT
RIGHT POWER MIRROR
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit, with defogger hybrid -> RIGHT DN LEFT UP RIGHT UP LEFT DN SWITCH 1 SWITCH 2
