Honda Civic VII facelift (2003-2006) left brake light/ tail- light Wiring diagram
This page shows the only wiring diagram for the component.left brake light/ tail- light, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left brake light/ tail- light (1 of 1)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
COUPE LX, EX
COUPE, SEDAN
CRUISE CONTROL ACTUATOR (RIGHT SIDE OF ENGINE COMPT)
CRUISE CONTROL UNIT (UNDER LEFT SIDE OF DASH)
ECM/PCM (BEHIND GLOVE BOX)
FROM TAILLIGHT RELAY (DIAGRAM 1 OF 2)
FUSE 7
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT BRAKE LIGHT/ TAIL- LIGHT
LEFT INNER TAILLIGHT (SEDAN)
LICENSE PLATE LIGHT
RED/YEL WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT INNER TAILLIGHT (SEDAN)
SEDAN COUPE 3 1 4 2
SEDAN COUPE 4 2 3 1
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
USA HX, SEDAN LX, GX, EX
W/ ACCESSORY REAR SPOILER
W/O ACCESSORY REAR SPOILER
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Exterior lamps circuit, except hatchback & hybrid (2 of 2) -> LEFT BRAKE LIGHT/ TAIL- LIGHT
