Honda Civic VII facelift (2003-2006) knock sensor shield mcm shield Wiring diagram
This page shows the only wiring diagram for the component.knock sensor shield mcm shield, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram knock sensor shield mcm shield (1 of 1)
AUDIO UNIT
BATTERY
BLK WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRN WIRE
CKP SENSOR IAC VALVE
CMP SENSOR ECM
CVT
DATA LINK CONNECTOR
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
FRONT IGNITION COIL 1 FRONT IGNITION COIL 2
FRONT IGNITION COIL 3
FRONT IGNITION COIL 4 REAR IGNITION COIL 1 REAR IGNITION COIL 2
JUNCTION
JUNCTION CONNECTOR
KNOCK SENSOR SHIELD MCM SHIELD
M/T
MCM
MCM SHIELD
MPI MODULE
NEUTRAL POSITION SWITCH
REAR IGNITION COIL 3
REAR IGNITION COIL 4
REAR WINDOW DEFOGGER
RED/WHT WIRE
SHIELD
TRANSMISSION
TRANSMISSION RANGE SWITCH
VTEC SOLENOID VALVE
YEL WIRE
Go to component -> Ground distribution circuit, hybrid (1 of 3) -> KNOCK SENSOR SHIELD MCM SHIELD
