Honda Civic VII facelift (2003-2006) high beam indicator Wiring diagrams
This page contains all the electrical diagrams for the component. high beam indicator, in which he is found in the car Honda Civic VII facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high beam indicator (1 of 6)
B+ DAY LT
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LEVEL SWITCH
BRAKE SYSTEM INDICATOR
BUS -
COMBINATION LIGHT SWITCH
DIMMER HI
DIMMER SWITCH
DRL CONTROL UNIT
DRL DIODE
DRL H/L SW
DRL INDICATOR
DRL RELAY
ELD UNIT
FUSE 10
FUSE 12
FUSE 15
FUSE 17
FUSE 19
FUSE 3
GAUGE ASSEMBLY
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
H/L HI
H/L LOW
HEAD PARK
HEAD PARK OFF
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HI LO
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LEFT HEADLIGHT
LIGHT RELAY
LO HI
MULTIPLEX CONTROL UNIT
OFF
OFF FLASH-TO- PASS SWITCH
PARKING BRAKE SWITCH (AT BASE OF PARK LEVER)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (UNDER LEFT SIDE OF DASH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, hybrid with drl -> HIGH BEAM INDICATOR
Wiring diagram high beam indicator (2 of 6)
BLK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER HI
DIMMER SWITCH
DRL H/L SW
ELD UNIT
FUSE 15
FUSE 17
FUSE 19
GAUGE ASSEMBLY
H/L HI
H/L LOW
HEAD
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HI LO
HIGH BEAM INDICATOR
HOT AT ALL TIMES
LEFT HEADLIGHT
LIGHT RELAY
MULTIPLEX CONTROL UNIT
OFF FLASH-TO- PASS SWITCH
PARK OFF HEAD
PARK OFF HEADLIGHT SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (UNDER LEFT SIDE OF DASH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
Go to component -> Headlights circuit, hybrid without drl -> HIGH BEAM INDICATOR
Wiring diagram high beam indicator (3 of 6)
BLU WIRE
BLU/WHT WIRE
BUS (SEFMJ)
COOLANT TEMPERATURE GAUGE
DASH LIGHTS BRIGHTNESS CONTROLLER
DASH, CONSOLE LIGHTS
DIMMING CIRCUIT
DRIVE CIRCUIT
DRIVER CIRCUIT
ECM/PCM (BEHIND GLOVE BOX)
FUEL GAUGE
FUSE 9
GAUGE ASSEMBLY
GAUGE LIGHTS
GRN/ORG WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
IMMOBILIZER SYSTEM INDICATOR
LCD BACK LIGHT
MIL CTRL
ODO/TRIP LCD BACK LIGHT STABILIZING POWER CIRCUIT
ODOMETER/TRIP LCD DISPLAY
PCM (BEHIND GLOVE BOX)
RED WIRE
RPM OUT (NEP)
SENSOR INPUT
SOLID STATE
SPEEDOMETER
TACHOMETER
TEST TACHOMETER CONNECTOR (RIGHT SIDE OF ENGINE COMPT)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VSSOUT
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, dx, gx (2 of 2) -> HIGH BEAM INDICATOR
Wiring diagram high beam indicator (4 of 6)
BLU WIRE
BLU/WHT WIRE
BUS (SEFMJ)
COOLANT TEMPERATURE GAUGE
DIMMING CIRCUIT
DRIVE CIRCUIT
DRIVER CIRCUIT
ECM/ PCM (BEHIND GLOVE BOX)
FROM LEFT TURN SIGNAL IND (DIAGRAM 1 OF 2)
FROM TRIP/ RESET SIGNAL (DIAGRAM 1 OF 2)
FUEL GAUGE
FUSE 9
GAUGE ASSEMBLY
GAUGE LIGHTS
GRN/ORG WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
MIL CTRL
ODOMETER/TRIP LCD DISPLAY
PCM (BEHIND GLOVE BOX)
RED WIRE
RPM OUT (NEP)
SENSOR INPUT
SPEEDOMETER
TACHOMETER
TEST TACHOMETER CONNECTOR (RIGHT SIDE OF ENGINE COMPT)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VSSOUT
W/ DRL
W/O DRL
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, ex, hx, lx (2 of 2) -> HIGH BEAM INDICATOR
Wiring diagram high beam indicator (5 of 6)
BLU WIRE
BUS (SEFMJ)
COOLANT TEMPERATURE GAUGE
DRIVE CIRCUIT
ECM (BEHIND GLOVE BOX)
ECT SENSOR (MIDDLE OF ENGINE)
EPS CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
FUEL GAUGE
FUSE 9
GAUGE ASSEMBLY
GAUGE LIGHTS
GAUGES/ INDICATORS
GRN/ORG WIRE
GRN/YEL WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
IMMOBILIZER SYSTEM INDICATOR
LCD BACK LIGHT
MIL CNTRL
ODO/TRIP LCD BACK LIGHT STABILIZING POWER CIRCUIT
ODOMETER/ TRIP DISPLAY
RED WIRE
RED/WHT WIRE
RPM OUT (NEP)
SENSOR INPUT
SNS IN (ECT)
SPEEDOMETER
TACHOMETER
TEST TACHOMETER CONNECTOR (RIGHT SIDE OF ENGINE COMPT)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, hatchback (2 of 2) -> HIGH BEAM INDICATOR
Wiring diagram high beam indicator (6 of 6)
