Honda Civic VII facelift (2003-2006) headliglht switch Wiring diagram
This page shows the only wiring diagram for the component.headliglht switch, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headliglht switch (1 of 1)
+B BACKUP
ALTERNATOR
BEEPER
BLK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DRIVER DOOR SWITCH
DRIVER SEAT BELT/SRS
DRIVER'S DOOR SWITCH
DRIVER'S SEAT BELT SWITCH
ECM/PCM (BEHIND GLOVE BOX)
FUSE 10
FUSE 3
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
GROUND
HEAD PARK
HEADLIGHT SWITCH
HEADLIGLHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
ILLUMMINATION (+)
KEY SWITCH INPUT
LOW OIL PRESSURE INDICATOR
LT GRN WIRE
MULTIPLEX BUS
MULTIPLEX CONTROL UNIT
OIL PRESSURE SWITCH
RED/BLU WIRE
RED/WHT WIRE
SECURITY CONTROL UNIT CONNECTOR
SMALL
TAILLIGHT RELAY
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Warning systems circuit, hatchback -> HEADLIGLHT SWITCH
