Honda Civic VII facelift (2003-2006) front passenger's door switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door switch, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door switch (1 of 1)
2 1 (SEDAN) (COUPE)
3 1 (COUPE) (SEDAN)
BLK WIRE
CEILING LIGHT
D/L SIL-CON SW
DOOR
DOOR LOCKS SYSTEM
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR SWITCH
FR DOOR SWITCH
FRONT PASSENGER'S DOOR SWITCH
FUSE 3
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
IGNITION KEY LIGHT
IGNITION KEY SWITCH
IGNITION LEY SWITCH/KEY LIGHT
INTR LT-
KEY LT-
KEY SW
LEFT REAR DOOR SWITCH (SEDAN)
LT GRN WIRE
LT GRN/RED WIRE
MULTIPLEX CONTROL UNIT
OFF
REAR DOOR SWITCHES
RED WIRE
RED/WHT WIRE
RIGHT REAR DOOR SWITCH (SEDAN)
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (UNDER LEFT SIDE OF DASH)
SEDAN
SPOTLIGHTS
TRUNK LATCH SWITCH
TRUNK LIGHT
TRUNK SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
WHT/BLK WIRE
WHT/BLU WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit, without sunroof -> FRONT PASSENGER'S DOOR SWITCH
