Honda Civic VII facelift (2003-2006) except dx Wiring diagrams
This page contains all the electrical diagrams for the component. except dx, in which he is found in the car Honda Civic VII facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram except dx (1 of 3)
1 2 (EXCEPT SEDAN) (SEDAN)
3 4 (EXCEPT SEDAN) (SEDAN) CRUISE CONTROL MAIN SWITCH
A/C CONDENSER FAN MOTOR
BLK WIRE
BLOWER MOTOR RELAY ELD UNIT
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CEILING LIGHT/ SPOTLIGHTS
COUPE LX, EX
CRUISE CONTROL ACTUATOR
CRUISE CONTROL UNIT
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S POWER WINDOW MOTOR
EXCEPT ABS
EXCEPT DX
EXCEPT DX, HX
FUEL PRESSURE REGULATOR SHUT-OFF SOLENOID VALVE
FUEL PRESSURE REGULATOR SWITCH
GAUGE ASSEMBLY
GND GND GND
LEFT FRONT TURN SIGNAL/ SIDE MARKER/ PARKING LIGHT
LEFT HEADLIGHT
MOONROOF OPEN RELAY MOONROOF CLOSE RELAY
MOONROOF SWITCH
MULTIPLEX CONTROL UNIT
MULTIPLEX CONTROL UNIT SERVICE CHECK CONNECTOR) (NOT USED)
PARK PIN/ SHIFT SWITCH WINDSHIELD WIPER MOTOR
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PSP SWITCH
RADIATOR FAN MOTOR
RIGHT FRONT TURN SIGNAL/ SIDE MARKER/ PARKING LIGHT
RIGHT HEADLIGHT
TURN SIGNAL/ HAZARD RELAY
USA
USA HX, SEDAN LX EX, GX
WINDSHIELD WASHER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit, except hatchback & hybrid (2 of 3) -> EXCEPT DX
Wiring diagram except dx (2 of 3)
A/F SENSOR RELAY (HX, DX, EX, LX)
BLOWER MOTOR RELAY
CANADA
DRL CONTROL UNIT
EXCEPT DX
FROM UNDERHOOD FUSE/RELAY BOX
FUSE 11 (SEDAN) (COUPE)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 5 (NOT USED)
FUSE 7
GRN WIRE
HATCHBACK
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
MOONROOF CLOSE RELAY MOONROOF OPEN RELAY
MULTIPLEX CONTROL UNIT
POWER WINDOW RELAY
REAR WINDOW DEFOGGER RELAY
RED/BLU WIRE
SECURITY CONTROL UNIT
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
W/O ACCESSORY INSTALLED W/ ACCESSORY INSTALLED
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 4) -> EXCEPT DX
Wiring diagram except dx (3 of 3)
3 4 (LX, DX, GX) (EX)
ALTERNATOR
BLK ORG/ WIRE
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
COUPE LX, EX
CRUISE CONTROL ACTUATOR
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL UNIT
ELD UNIT
EVAP CANISTER PURGE VALVE VSS
EX, HATCHBACK
EXCEPT DX
EXCEPT GX, HATCHBACK
FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 3 OF 4)
FUSE 1
FUSE 4
FUSE 6
HATCHBACK
HATCHBACK SEDAN/COUPE
HATCHBACK, EXCEPT GX HATCHBACK, EXCEPT CVT
IGNITION COIL 1
IGNITION COIL 2 IGNITION COIL 3
IGNITION COIL 4
LX, DX, GX, HX
MOONROOF CLOSE RELAY
MOONROOF CONTROL UNIT (HATCHBACK)
MOONROOF OPEN RELAY
ORG/ WIRE
POWER WINDOW RELAY
PRIMARY
SECONDARY
SECONDARY CMP SENSOR
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF OF ENGINE COMPARTMENT)
USA
USA HX, SEDAN LX, EX, GX, HATCHBACK
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit, except hybrid (4 of 4) -> EXCEPT DX
