Honda Civic VII facelift (2003-2006) except cvt Wiring diagrams
This page contains all the electrical diagrams for the component. except cvt, in which he is found in the car Honda Civic VII facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram except cvt (1 of 3)
A/T
A/T REVERSE RELAY (BEHIND GLOVE BOX)
BACK-UP LIGHT SWITCH (ON TRANSAXLE HOUSING)
BLK WIRE
CVT
EXCEPT CVT
FUSE 10
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN ON OR START
HX, LX, EX EXCEPT HX, LX, EX
JUNCTION
M/T
ORG/ WIRE
PCM (BEHIND GLOVE BOX)
RIGHT BACK-UP LIGHT LEFT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Back-up lamps circuit, except hatchback & hybrid -> EXCEPT CVT
Wiring diagram except cvt (2 of 3)
A/T
A/T EXCEPT CVT
A/T EXCEPT CVT, CVT
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU (OR LT GRN) WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CABLE REEL (ON STEERING COLUMN)
CANCEL SWITCH
CLUTCH PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
COUPE LX, EX
CRUISE CONTROL ACTUATOR (USA HX, SEDAN LX, EX, GX) (RIGHT SIDE OF
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SET/RESUME CANCEL SWITCH
CRUISE CONTROL SWITCH LIGHT
CRUISE INDICATOR
CVT
ECM/PCM (BEHIND GLOVE BOX)
EXCEPT CVT
EXCEPT HX, LX, EX
FUSE 10
FUSE 4
FUSE 7
GAUGE ASSEMBLY
GRN WIRE
GRY WIRE
GRY/RED WIRE
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
HX, LX, EX
JUNCTION
JUNCTION CONNECTOR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
M/T
MULTIPLEX CONTROL UNIT
OF ENGINE COMPT)
OFF
ON INDICATOR
ORG/ WIRE
PCM (BEHIND GLOVE BOX)
PNK WIRE
RED WIRE
RESUME + SWITCH
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (UNDER LEFT SIDE OF DASH)
SET SWITCH
STEERING WHEEL)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
USA HX, SEDAN LX, EX, GX COUPE LX, EX
VSS (ON TRANSMISSION HOUSING)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Cruise control circuit, except hatchback & hybrid -> EXCEPT CVT
Wiring diagram except cvt (3 of 3)
3 1 IGNITION KEY SWITCH
ATP-P
BKSW
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH
CVT
ECM/PCM (BEHIND GLOVE BOX)
EXCEPT CVT
FUSE 10
FUSE 7
GAUGE ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR START
HOUSING)
IGNITION KEY SWITCH/ KEY LIGHT
ILU
KEY INTERLOCK SOLENOID
KEY SOLENOID OUTPUT
KEY SWITCH INPUT
MULTIPLEX CONTROL UNIT
ORG/ WIRE
PARK PIN/ SHIFT SWITCH (BEHIND A/T SHIFT LEVER)
PARK PIN/SHIFT SWITCH
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (UNDER LEFT SIDE OF DASH)
SHIFT LOCK SOLENOID (BESIDE A/T SHIFT LEVER)
SHIFT-LOCK SOL
STOP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Shift interlock circuit, except hybrid -> EXCEPT CVT
