Honda Civic VII facelift (2003-2006) dlc input/out dlc input/out Wiring diagram
This page shows the only wiring diagram for the component.dlc input/out dlc input/out, which is found in the car Honda Civic VII facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dlc input/out dlc input/out (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 RRS- RRS+
ABS INDICATOR CIRCUIT
ABS INDICATOR LIGHT
ABS MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRAKE SW IN IGN INPUT GROUND B+ B+ GROUND ABS INDIC EBD
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DLC INPUT/OUT DLC INPUT/OUT
EBD
FRS- FRS+ FLS- FLS+ RLS- RLS+
FUSE 10
FUSE 11
FUSE 7
FUSE 8
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
GX EX
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL)
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL) (AT LEFT SIDE OF ENGINE COMPT)
LT BLU WIRE
MULTIPLEX CONTROL UNIT
ORG/ WIRE
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL)
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit, except hatchback & hybrid -> DLC INPUT/OUT DLC INPUT/OUT
