Honda Civic VII facelift (2003-2006) carlink interface box Wiring diagrams
This page contains all the electrical diagrams for the component. carlink interface box, in which he is found in the car Honda Civic VII facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram carlink interface box (1 of 3)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
AUDIO UNIT
BATTERY
BLK WIRE
BLU WIRE
CARLINK INTERFACE BOX
CVT
DC-DC CONVERTER
DLC
ELECTRICAL LOAD DETECTOR UNIT FUSE 20
FUSE 1
FUSE 19
FUSE 2
FUSE 3
FUSE 4
FUSE 6
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
IGNITION KEY SWITCH/ KEY LIGHT CEILING LIGHT TRUNK LIGHT
IGNITION SWITCH
IMMOBILIZER CONTROL UNIT- RECEIVER
KEYLESS RECEIVER UNIT
LOCK
MCM RELAY 2
MOTOR CONTROL MODULE
MULTIPLEX CONTROL UNIT B+ BACK UP
ON OFF
PGM-FI MAIN RELAY 1
RADIATOR FAN RELAY
RED WIRE
SPOTLIGHTS
STARTER
STARTER SOLENOID
TAILLIGHT RELAY
TCM
TO FUSE 10 (DIAGRAM 3 OF 4)
TO FUSE 13 (DIAGRAM 2 OF 4)
TO FUSE 14 (DIAGRAM 3 OF 4)
TO FUSE 21 (DIAGRAM 3 OF 4) TO FUSE 8 (DIAGRAM 3 OF 4)
TO FUSE 5 (DIAGRAM 2 OF 4)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
W/ CARLINK
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 4) -> CARLINK INTERFACE BOX
Wiring diagram carlink interface box (2 of 3)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
A/T REVERSE RELAY
ABS MODULATOR CONTROL UNIT
AUDIO UNIT
BACK-UP LIGHT SWITCH (M/T) EPS CONTROL UNIT
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY REAR WINDOW DEFOGGER RELAY
BLU WIRE
BLU/ORG WIRE
CANADA
CARLINK INTERFACE BOX
CARLINK INTERFACE BOX (IF EQUIPPED)
CIGARETTE LIGHTER OR ACCESSORY POWER SOCKET
CLIMATE CONTROL UNIT
CVT
DAY LT
DRL CONTROL UNIT (CANADA)
FROM IGNITION SWITCH (DIAGRAM 1 OF 4)
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 18
FUSE 21
FUSE 8
FUSE 9
GAUGE ASSEMBLY
JUNCTION CONNECTOR
KEYLESS RECEIVER UNIT
MCM
METER
MULTIPLEX CONTROL UNIT
PNK (OR WIRE
POWER MIRROR SWITCH
RADIATOR FAN RELAY
REAR IGNITION COIL 1 REAR IGNITION COIL 2
REAR IGNITION COIL 3
REAR IGNITION COIL 4
REAR WINDOW DEFOGGER SWITCH
RECIRCULATION CONTROL MOTOR
RED WIRE
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL)
SHIFT LOCK SOLENOID
SRS UNIT
STARTER CUT RELAY
TO FUSE 17 (DIAGRAM 4 OF 4)
UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
W/ CARLINK
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit, hybrid (3 of 4) -> CARLINK INTERFACE BOX
Wiring diagram carlink interface box (3 of 3)
