Car Wiring Diagrams for Warning system circuits for Honda Civic VII (2000-2003)

BEEPER BLK WIRE BLU WIRE BLU/RED (OR GRN) WIRE BLU/RED WIRE COMBINATION LIGHT SWITCH DRIVER DOOR SWITCH DRIVER SEAT BELT/SRS DRIVER'S DOOR SWITCH DRIVER'S SEAT BELT SWITCH (UNDER DRIVER'S SEAT) ECM/PCM (BEHIND GLOVE BOX) FUSE 10 FUSE 12 FUSE 20 FUSE 3 FUSE 8 FUSE 9 FUSE 9 (UNDERHOOD) GAUGE ASSEMBLY GRN WIRE GRN/WHT WIRE GROUND HEAD PARK HEADLIGHT SWITCH HEADLIGLHT SWITCH HOT AT ALL TIMES HOT IN ON HOT IN ON OR IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT KEY SWITCH INPUT GROUND LEFT REAR DOOR SWITCH LT GRN (OR GRN) WIRE LT GRN/RED WIRE MULTIPLEX BUS MULTIPLEX CONTROL UNIT PASSENGER DOOR SWITCH PASSENGER'S DOOR SWITCH REAR DOOR SWITCHES RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR DOOR SWITCH SECURITY CONTROL UNIT CONNECTOR (UNDER LEFT SIDE OF DASH) TRUNK LATCH SWITCH UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) WHT/GRN WIRE WHT/RED WIRE YEL WIRE
