Courtesy lamps circuit, without sunroof for Honda Civic VII (2000-2003)
Courtesy lamps circuit, without sunroof
BLK WIRE
CEILING LIGHT
DRIVER'S DOOR SWITCH
FR DOOR SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY BOX FUSE 3 (RIGHT SIDE OF ENGINE COMPT)
INTR LT-
LEFT REAR DOOR SWITCH (SEDAN) RIGHT REAR DOOR SWITCH (SEDAN)
LT GRN WIRE
LT GRN/RED WIRE
MULTIPLEX CONTROL UNIT TRUNK SWITCH (RIGHT SIDE OF ENGINE COMPT)
OFF
OFF DOOR
PASSENGER'S DOOR SWITCH
REAR DOOR SWITCHES
RED WIRE
SECURITY CONTROL UNIT CONNECTOR
SPOTLIGHTS
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
WHT/BLU WIRE
