Manual a/c circuit for Honda Civic VII (2000-2003)

A/C AIR DELIVERY COMPRESSOR CNTRLS AIR DELIVERY AIR DELIVERY COMPRESSOR CNTRLS AIR MIXTURE CONTROL MOTOR (ON LEFT SIDE OF HVAC ASSEMBLY) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER POWER TRANSISTOR (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR) BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE DEFOGGER SYSTEM DEFROST EVAPORATOR TEMPERATURE SENSOR (ON CENTER OF HVAC ASSEMBLY) GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEATER CONTROL PANEL HOT IN ON FUSE 14 ILLUM ILLUMINATION ILLUMINATION LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MODE CONTROL MOTOR (ON CENTER OF HVAC ASSEMBLY) PNK/BLK WIRE PNK/BLU WIRE RECIRC RECIRC-A/C-REAR DEFFOGGER SWITCH ASSEMBLY RECIRCULATION CONTROL MOTOR (ON CENTER OF HVAC ASSEMBLY) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/C CLUTCH A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C COMPRESSOR THERMAL PROTECTOR A/C CONDENSER FAN MOTOR (FORWARD OF RADIATOR) A/C PRESSURE SWITCH (BEHIND LEFT SIDE OF A/C CONDENSER FAN) ACCESSORY A/C ACS BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CONDENSER FAN RELAY ECM/PCM (BEHIND GLOVE BOX) FACTORY A/C FUSE 1 FUSE 12 FUSE 4 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES MULTIPLEX CONTROL UNIT NCA WIRE RADIATOR FAN MOTOR (BEHIND RADIATOR) RADIATOR FAN RELAY RADIATOR FAN SWITCH (MIDDLE OF ENGINE) RED WIRE SEFMJ UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
