Honda Civic VII (2000-2003) underdash fuse/relay box Wiring diagrams
This page contains all the electrical diagrams for the component. underdash fuse/relay box, in which he is found in the car Honda Civic VII (2000-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram underdash fuse/relay box (1 of 7)
A/T
A/T REVERSE RELAY (BEHIND GLOVEBOX)
BACK-UP LIGHT SWITCH (TRANSMISSION HOUSING)
BLK WIRE
CVT
EXCEPT CVT
FUSE 10
GRN WIRE
GRN/WHT WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
JUNCTION
M/T
ORG/ WIRE
RIGHT BACK-UP LIGHT LEFT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (TRANSMISSION HOUSING)
UNDERDASH FUSE/RELAY BOX
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Back-up lamps circuit -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (2 of 7)
ANTI-THEFT SYSTEM
BEEPER
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED (OR GRN) WIRE
BLU/RED WIRE
BLU/WHT WIRE
CANADA
DOOR LOCKS SYSTEM
DRIVER DR LOCK REMOTE IN
DRIVER DR UNLK REMOTE IN
ECM/PCM (BEHIND GLOVE BOX)
EXTERIOR LIGHTS, CRUISE CONTROL SYSTEMS INTERIOR LIGHTS SYSTEM
FUSE 10
FUSE 12
FUSE 16
FUSE 20
FUSE 3
FUSE 8
FUSE 9
FUSE 9 (UNDERHOOD) GROUND HORN RELAY FUSE 16 (UNDERHOOD)
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND DRIVER DOOR UNLOCK INPUT DRIVER DOOR LOCK INPUT
GROUND SECURITY ALARM SYSTEM SECURITY ALARM SYSTEM
HEADLIGHTS BRAKE SWITCH A/C PRESSURE SWITCH HEADLIGHTS
HEADLIGHTS SYSTEM
HEADLIGLHT SWITCH
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR
IGNITION KEY LIGHT
IGNITION KEY SWITCH/ KEY LIGHT
KEY SOLENOID OUTPUT
KEY SWITCH INPUT
LT GRN/RED WIRE
MIST WIPER INPUT HEADLIGHTS HEADLIGHTS IMMOBILIZER
MULTIPLEX BUS
MULTIPLEX BUS PCM
MULTIPLEX CONTROL UNIT
ORG/ WIRE
PARK PIN/SHIFT SWITCH SHIFT LOCK SOLENOID PARK PIN/SHIFT SWITCH
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SHIFT INTERLOCK SYSTEM
SHIFT INTERLOCK SYSTEM ANTI-THEFT SYSTEM
TRANSMISSION RANGE SW
UNDERDASH FUSE/RELAY BOX
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WARNING SYSTEMS
WASHER MOTOR
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER INTERMITTENT INPUT IGNITION KEY INPUT
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM EXTERIOR, INTERIOR LIGHTS SYSTEMS
WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM AIR CONDITIONING SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Body computer circuits -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (3 of 7)
BLK WIRE
BLU WIRE
CEILING LIGHT/SPOTLIGHTS
DRIVER'S DOOR SWITCH
FR DOOR SWITCH
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY BOX FUSE 3 (RIGHT SIDE OF ENGINE COMPT)
INTR LT- FR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
MULTIPLEX CONTROL UNIT TRUNK SWITCH (RIGHT SIDE OF ENGINE COMPT)
OFF
OFF CEILING LIGHTS
OFF DOOR
ON DOOR
ON SPOT- LIGHTS OFF
PASSENGER'S DOOR SWITCH
REAR CEILING LIGHT
RED WIRE
SECURITY CONTROL UNIT CONNECTOR
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit, coupe with sunroof -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (4 of 7)
BLK WIRE
CEILING LIGHT/SPOTLIGHTS
DRIVER'S DOOR SWITCH
FR DOOR SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY BOX FUSE 3 (RIGHT SIDE OF ENGINE COMPT)
INTR LT- REAR DOOR SWITCHES
LEFT REAR DOOR SWITCH RIGHT REAR DOOR SWITCH
LT GRN WIRE
LT GRN/RED WIRE
MULTIPLEX CONTROL UNIT TRUNK SWITCH (RIGHT SIDE OF ENGINE COMPT)
OFF
OFF CEILING LIGHTS
OFF DOOR
ON DOOR
ON SPOT- LIGHTS OFF
PASSENGER'S DOOR SWITCH
REAR CEILING LIGHT
RED WIRE
SECURITY CONTROL UNIT CONNECTOR
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit, sedan with sunroof -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (5 of 7)
BLK WIRE
CEILING LIGHT
DRIVER'S DOOR SWITCH
FR DOOR SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY BOX FUSE 3 (RIGHT SIDE OF ENGINE COMPT)
INTR LT-
LEFT REAR DOOR SWITCH (SEDAN) RIGHT REAR DOOR SWITCH (SEDAN)
LT GRN WIRE
LT GRN/RED WIRE
MULTIPLEX CONTROL UNIT TRUNK SWITCH (RIGHT SIDE OF ENGINE COMPT)
OFF
OFF DOOR
PASSENGER'S DOOR SWITCH
REAR DOOR SWITCHES
RED WIRE
SECURITY CONTROL UNIT CONNECTOR
SPOTLIGHTS
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit, without sunroof -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (6 of 7)
Go to component -> Horn circuit -> UNDERDASH FUSE/RELAY BOX
Wiring diagram underdash fuse/relay box (7 of 7)
BEEPER
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRAKE PEDAL SW MULTIPLEX BUS INTERLOCK CTRL OUTPUT
FUSE 10
FUSE 12
FUSE 16
FUSE 16 (UNDERHOOD)
FUSE 20
FUSE 3
FUSE 7
FUSE 8
FUSE 9
FUSE 9 (UNDERHOOD) GROUND
GAUGE ASSEMBLY
GROUND
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
KEY INTELOCK SOLENOID
KEY SOLENOID OUTPUT
KEY SWITCH INPUT
MULTIPLEX BUS
MULTIPLEX BUS PCM
MULTIPLEX CONTROL UNIT
ORG/ WIRE
PARK PIN/ SHIFT SWITCH (BEHIND A/T SHIFT LEVER)
PARK PIN/SHIFT SWITCH
POWERTRAIN CONTROL MODULE (BEHIND GLOVE BOX)
RED/WHT WIRE
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID (BEHIND A/T SHIFT LEVER)
STOP LIGHT
TRANSMISSION RANGE SW
TRANSMISSION RANGE SWITCH (TRANSMISSION HOUSING)
UNDERDASH FUSE/RELAY BOX
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
W/ CVT
W/O CVT
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Shift interlock circuit -> UNDERDASH FUSE/RELAY BOX
