Honda Civic VII (2000-2003) side airbag indicator Wiring diagrams
This page contains all the electrical diagrams for the component. side airbag indicator, in which he is found in the car Honda Civic VII (2000-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram side airbag indicator (1 of 2)
A/T REVERSE RELAY (BEHIND GLOVE BOX)
ABS INDICATOR
ABS INDICATOR CIRCUIT
BEEPER
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE LEVEL SW
BUS (SEFMJ)
BUS METER
CHARGING SYSTEM INDICATOR
CRUISE CONTROL INDICATOR
CRUISE CONTROL SYSTEM
CVT
DOOR INDICATOR LIGHT
DRIVE CIRCUIT
DRL CONTROL UNIT (UNDER LEFT SIDE OF DASH)
DRL INDICATOR
EXCEPT CVT
EXCEPT GX
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT (ON TOP OF FUEL TANK)
FUSE 10 FUSE 4
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/RED (OR GRN/ORG) WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
HOT IN ON OR START
IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER)
J/C
LEFT TURN SIGNAL INDICATOR
LOW FUEL INDICATOR
LOW OIL PRESSURE INDICATOR
MAINTENANCE REQUIRED INDICATOR
MALFUNCTION INDICATOR
METER
MULTIPLEX CONTROL UNIT ATP-P
OIL PRESSURE SWITCH (NEAR OIL FILTER)
ORG/ WIRE
PARKING BRAKE, BRAKE SYSTEM INDICATOR
PNK WIRE
PNK/BLU WIRE
POWER CIRCUIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT TURN SIGNAL INDICATOR
SEAT BELT REMINDER
SIDE AIRBAG INDICATOR
SRS INDICATOR
SRS INDICATOR CIRCUIT
SUPPLEMENTAL RESTRAINTS SYSTEM
SWITCH TRIP/RESET
TRUNK INDICATOR LIGHT
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
USA CANADA
VSS (TRANSMISSION HOUSING)
WASHER FLUID LEVEL SWITCH (CANADA) (BEHIND LEFT SIDE OF FRONT BUMPER)
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER/WASHER INDICATOR (CANADA)
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> SIDE AIRBAG INDICATOR
Wiring diagram side airbag indicator (2 of 2)
BLK (OR BLU) WIRE
BLK (OR BRN) WIRE
BLK WIRE
BLU WIRE
BLU/BLK (OR BLU) WIRE
BLU/RED (OR BLU) WIRE
BLU/YEL (OR BLU) WIRE
DRIVER'S SEAT BELT TENSIONER
FRONT PASSENGER'S AIRBAG FIRST INFLATOR
FRONT PASSENGER'S AIRBAG SECOND INFLATOR
FRONT PASSENGER'S SEAT BELT TENSIONER
FUSE 10
FUSE 9
GAUGE ASSEMBLY
GRN (OR BLU) WIRE
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT FRONT INPACT SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER)
LOWER ELEMENT (SEAT BOTTOM CUSHION)
ODUS GND
OPDS SENSOR (W/ SIDE AIRBAG)
OPDS UNIT (W/ SIDE AIRBAG) (IN FRONT PASSENGER'S SEAT)
PNK WIRE
POW WRN
RED (OR BLU) WIRE
RED (OR BRN) WIRE
RED WIRE
RED/BLK (OR BLU) WIRE
RED/BLK (OR GRN) WIRE
RED/BLU (OR BLU) WIRE
RED/BLU (OR GRN) WIRE
RED/WHT (OR BLU) WIRE
RED/WHT (OR GRN) WIRE
RED/YEL (OR BLU) WIRE
RED/YEL (OR GRN) WIRE
RIGHT FRONT INPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
SIDE AIRBAG INDICATOR
SIDE ELEMENT (RIGHT SIDE OF SEAT)
SRS INDICATOR
SRS INDICATOR CIRCUIT
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UPPER ELEMENT (SEAT BACK)
WHT WIRE
WHT/RED WIRE
YEL (OR BLU) WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit (2 of 2) -> SIDE AIRBAG INDICATOR
