Honda Civic VII (2000-2003) multiplex control unit service check connector Wiring diagram
This page shows the only wiring diagram for the component.multiplex control unit service check connector, which is found in the car Honda Civic VII (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multiplex control unit service check connector (1 of 1)
+B BACKUP
ABS MODULATOR CONTROL UNIT (LEFT SIDE OF ENGINE COMPARTMENT)
AUDIO UNIT
BLK WIRE
BRN WIRE
BRN/YEL WIRE
COMMUNICATION
ENGINE OR POWERTRAIN CONTROL MODULE (ECM/PCM) (BEHIND GLOVE BOX)
FUSE 10
FUSE 9
GAUGE ASSEMBLY
GRN/ORG WIRE
GROUND GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMMOBILIZER CONTROL UNIT (IN STEERING COLUMN COVER)
INJECTOR CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT) (GX ONLY)
K LINE
KEYLESS RECEIVER UNIT (EX ONLY)
LT BLU WIRE
MPCS CHECK GROUND
MULTIPLEX CONTROL UNIT
MULTIPLEX CONTROL UNIT SERVICE CHECK CONNECTOR
RED WIRE
SCS
SEFMS BUS (METER)
SENSOR GROUND
SRS UNIT (UNDER MIDDLE OF DASH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Computer data lines -> MULTIPLEX CONTROL UNIT SERVICE CHECK CONNECTOR
