Honda Civic VII (2000-2003) heater control unit panel rear window defogger relay cntrl Wiring diagrams
This page contains all the electrical diagrams for the component. heater control unit panel rear window defogger relay cntrl, in which he is found in the car Honda Civic VII (2000-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heater control unit panel rear window defogger relay cntrl (1 of 2)
ANTENNA LEAD
ANTENNA MODULE
AUDIO UNIT
BLK WIRE
BLK/YEL WIRE
COIL ASSEMBLY
FUSE 11
FUSE 14
GRN WIRE
GROUND
HEATER CONTROL UNIT PANEL REAR WINDOW DEFOGGER RELAY CNTRL
HOT AT ALL TIMES
HOT IN ON
IGNITION INPUT
LEFT "C" PILLAR)
NCA WIRE
REAR WINDOW DEFOGGER (FM ANTENNA)
REAR WINDOW DEFOGGER RELAY
SUB-ANTENNA LEAD
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
WINDOW ANTENNA (AM)
YEL WIRE
Go to component -> Defogger circuit, coupe -> HEATER CONTROL UNIT PANEL REAR WINDOW DEFOGGER RELAY CNTRL
Wiring diagram heater control unit panel rear window defogger relay cntrl (2 of 2)
BLK WIRE
FUSE 11
FUSE 14
GRN WIRE
GROUND
HEATER CONTROL UNIT PANEL REAR WINDOW DEFOGGER RELAY CNTRL
HOT AT ALL TIMES
HOT IN ON
IGNITION INPUT
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
WINDOW ANTENNA COIL
YEL WIRE
Go to component -> Defogger circuit, sedan -> HEATER CONTROL UNIT PANEL REAR WINDOW DEFOGGER RELAY CNTRL
