Starting circuit, m/t for Honda Civic V (1991-1997)
Starting circuit, m/t
1995 VFTC IGNITION SWITCH
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CANADA ONLY
CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL SUPPORT)
ELEC- TRICAL LOAD DE- TECTOR (ELD) UNIT
ENGINE CONTROLS SYSTEM
HD IN
INTEGRATED CONTROL UNIT
LOCK (0)
ON (II) (I)
ORG/ WIRE
RED WIRE
SECURITY CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
SECURITY STARTER CUT RELAY (BEHIND LEFT KICK PANEL)
STARTER
STARTER CUT RELAY (BEHIND LEFT SIDE OF DASH)
STARTER SOLENOID PL IN
UNDER- DASH FUSE/ RELAY BOX FUSE 18
UNDER- HOOD FUSE/ RELAY BOX IG FUSE 39 USA ONLY
W/ ANTI- THEFT
W/ FIELD WINDING TYPE STARTER MOTOR
W/O ANTI- THEFT
WHT WIRE
WHT/BLK WIRE
