Charging circuit for Honda Civic V (1991-1997)
Charging circuit
1995 VFTC
ABS CONTROL UNIT (RIGHT SIDE OF LUGGAGE COMPT) ENG- INE RUN- NING INPUT
ALTERNATOR
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CHARGING SYSTEM INDICATOR
ELD IN- PUT
ELECTRICAL LOAD DETECTOR (ELD) UNIT (USA ONLT)
ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT KICK PANEL)
FR ALT FR SIG ALT OUTPUT SIG
FUSE 12 (W/O SRS ONLY)
FUSE 24
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GROUND
HOT IN ON OR START
IGNITION INPUT
J/C
LOAD OUTPUT
PNK WIRE
RED WIRE
SRS FUSE BLOCK (W/ SRS ONLY) (BEHIND LEFT SIDE OF DASH)
STARTER SOLENOID
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD ABS FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
USA ONLY
W/ SRS ONLY
WHT WIRE
WHT/BLU WIRE
YEL WIRE
