Headlight circuit, without drl for Honda Civic V (1991-1997)
Headlight circuit, without drl
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER SWITCH OFF HEAD
FLASH TO PASS SWITCH
FOG LIGHT IN LINE FUSE
FOG LIGHT RELAY (RIGHT SIDE OF STEERING COLUMN)
FOG LIGHT SWITCH
FUSE 10
FUSE 21
FUSE 22
FUSE 9
GAUGE ASSEMBLY
HEADLIGHT SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT (LOW)
LIGHT FUSE 40
LO PARK
OFF
ON OFF
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
UNDER-DASH FUSE/RELAY BOX (LEFT SIDE OF I/P)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
