Honda Civic V (1991-1997) Exterior light circuit, coupe & sedan
Exterior light circuit, coupe & sedan (1 of 2)
BLK WIRE
BRAKE LIGHT SWITCH (LEFT SIDE OF I/P)
COMBINATION LIGHT SWITCH
GRN/ WHT WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHT SWITCH HEAD OFF PARK
HIGH MOUNT BRAKE LIGHTS
HOT AT ALL TIMES
J/C
LEFT FRONT FENDER)
LEFT FRONT PARKING/TURN SIGNAL LIGHT
LEFT INNER BRAKE/TAIL- LIGHT
LEFT LICENSE LIGHT
LEFT OUTER BRAKE/TAIL- LIGHT
LEFT OUTER TAILLIGHT
LEFT TURN SIGNAL LIGHT
LIGHT FUSE 40
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT PARKING/TURN SIGNAL LIGHT
RIGHT INNER BRAKE/TAIL- LIGHT
RIGHT LICENSE LIGHT
RIGHT OUTER BRAKE/TAIL- LIGHT
RIGHT OUTER TAILLIGHT
RIGHT TURN SIGNAL LIGHT
STOP, HORN FUSE 42
TO HAZARD WARNING SWITCH (DIAGRAM 2 OF 2)
TO TURN SIGNAL SWITCH (DIAGRAM 2 OF 2)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P) FUSE 19
UNDER-HOOD FUSE/RELAY BOX
W/ CRUISE CONTROL
W/ SPOILER
W/O CRUISE CONTROL
W/O SPOILER
WHT GRN/ WIRE
WHT WIRE
WHT/GRN WIRE
Exterior light circuit, coupe & sedan (2 of 2)
BLK WIRE
COMBINATION LIGHT SWITCH
FROM LEFT FRONT PARKING/TURN SIGNAL LIGHT (DIAGRAM 1 OF 2)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
GAUGE ASSEMBLY
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
HAZARD FUSE 43
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX FUSE 15 (BEHIND LEFT SIDE OF I/P)
IGNITION
ILLUMINATION
J/C
LEFT
LEFT TURN INDIC
OFF
ON (NOT USED)
RED WIRE
RED/BLK WIRE
RELAY OUT
RIGHT
RIGHT TURN INDIC
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P)
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
