Cooling fan circuit for Honda Civic V (1991-1997)
Cooling fan circuit
1994, 1995
A/C COMPRESSOR CLUTCH RELAY
A/C DIODE
A/C HIGH PRESSURE SWITCH
A/C THERMOSTAT
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
CONDENSER FAN FUSE 35
CONDENSER FAN MOTOR
CONDENSER FAN RELAY (BEHIND LEFT SIDE OF FRONT BUMPER)
COOLING FAN FUSE 33
ENGINE CONTROL MODULE (AT RIGHT KICK PANEL)
ENGINE COOLANT TEMPERATURE SWITCH A (RIGHT REAR OF ENGINE)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON FUSE 13
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
