Honda Civic V (1991-1997) stop, horn fuse 42 back up fuse 32 Wiring diagrams

This page contains all the electrical diagrams for the component. stop, horn fuse 42 back up fuse 32, in which he is found in the car Honda Civic V (1991-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram stop, horn fuse 42 back up fuse 32 (1 of 3)

Wiring diagram stop, horn fuse 42 back up fuse 32 for Honda Civic V (1991-1997) (1 of 3)

Get access

A/T A/T GEAR POSITION INDICATOR A/T GEAR POSITION SWITCH (BELOW CENTER CONSOLE) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/BLK WIRE BRN/RED WIRE CKP SENSOR CLUTCH SWITCH (BEHIND LEFT SIDE OF DASH) CRUISE CONTROL CRUISE CONTROL UNIT CRUISE CONTROL UNIT, ODOMETER/TRIPMETER DRIVE CIRCUIT CYP SENSOR DISTRIBUTOR ASSEMBLY (RIGHT SIDE OF ENGINE) FUEL PUMP (BELOW CENTER OF REAR SEAT) FUSE 12 FUSE 24 GAUGE ASSEMBLY GRN (OR WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH HOT AT ALL TIMES UNDER- HOOD FUSE/ RELAY BOX ECU FUSE 31 HOT IN RUN OR START HOT W/ ENGINE CRANKING UNDER- DASH FUSE/ RELAY BOX FUSE 18 IGN GND RPM PWR IGNITION COIL IGNITION CONTROL MODULE KEY INTERLOCK SWITCH LOCK LT BLU WIRE M/T (USA CX) A/T M/T(USA CX) MALFUNCTION INDICATOR ORG/ WIRE ORG/BLU WIRE PGM-FI MAIN RELAY (LEFT KICK PANEL) PNK WIRE PNK/BLK WIRE PNK/BLK(OR GRN) WIRE PNK/GRN WIRE POWER STEERING PRESSURE SWITCH (CENTER REAR OF ENGINE) PRIMARY OUTPUT CONTROL RED WIRE SHIFT INTERLOCK SYSTEM SRS FUSE BLOCK STOP, HORN FUSE 42 BACK UP FUSE 32 TACHOMETER TDC SENSOR TEST TACHOMETER CONNECTOR) UNDER- DASH FUSE/ RELAY BOX UNDER- HOOD FUSE/ RELAY BOX UPSHIFT INDICATOR VEHICLE SPEED SENSOR (RIGHT REAR OF ENGINE COMPARTMENT) IGN VSS OUT VTEC PRESSURE SWITCH (VTEC ENGINES ONLY) (RIGHT SIDE OF ENGINE) W/ SRS W/O SRS WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 1.5ls (2 of 2) -> STOP, HORN FUSE 42 BACK UP FUSE 32

Wiring diagram stop, horn fuse 42 back up fuse 32 (2 of 3)

Wiring diagram stop, horn fuse 42 back up fuse 32 for Honda Civic V (1991-1997) (2 of 3)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/RED WIRE CKP SENSOR CLUTCH SWITCH (BEHIND LEFT SIDE OF DASH) CRUISE CONTROL UNIT CRUISE CONTROL UNIT, ODOMETER/TRIPMETER DRIVE CIRCUIT CYP SENSOR DISTRIBUTOR ASSEMBLY (RIGHT SIDE OF ENGINE) ELECTRICAL LOAD DETECTOR UNIT EXHAUST GAS RECIRCULATION CONTROL SOLENOID VALVE FUEL PUMP (BELOW CENTER OF REAR SEAT) FUSE 41 GAUGE ASSEMBLY GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH HOT AT ALL TIMES UNDER- HOOD FUSE/ RELAY BOX ECU FUSE 31 HOT IN RUN OR START SRS FUSE BLOCK FUSE 24 HOT IN START WITH CLUTCH PEDAL DEPRESSED IGN GND RPM PWR IGNITION COIL IGNITION CONTROL MODULE JUNCTION JUNCTION CONNECTOR LOCK LT BLU WIRE MALFUNCTION INDICATOR ORG/ WIRE ORG/BLU WIRE PGM-FI MAIN RELAY (LEFT KICK PANEL) PNK WIRE PNK/BLK WIRE PNK/GRN WIRE POWER STEERING PRESSURE SWITCH (CENTER REAR OF ENGINE) PRIMARY OUTPUT CONTROL RED WIRE RUN WIRE STOP, HORN FUSE 42 BACK UP FUSE 32 TACHOMETER TDC SENSOR TEST TACHOMETER CONNECTOR) UNDER- DASH FUSE/ RELAY BOX UNDER- DASH FUSE/ RELAY BOX FUSE 18 UNDER- HOOD FUSE/ RELAY BOX UNDERHOOD FUSE/RELAY BOX UPSHIFT INDICATOR VEHICLE SPEED SENSOR (RIGHT REAR OF ENGINE COMPT.) IGN VSS OUT VTEC PRESSURE SWITCH (RIGHT SIDE OF ENGINE) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 1.5l vtecs (2 of 2) -> STOP, HORN FUSE 42 BACK UP FUSE 32
