Honda Civic V (1991-1997) hatch latch switch Wiring diagrams
This page contains all the electrical diagrams for the component. hatch latch switch, in which he is found in the car Honda Civic V (1991-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hatch latch switch (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
COUPE, SEDAN
DISARM/ VALET SWITCH
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM WARNING SYSTEM INTERIOR LIGHTS SYSTEM
DRIVER'S DOOR SWITCH
EXTERIOR, INTERIOR LIGHTS SYSTEMS
FRONT PASSENGER'S DOOR SWITCH
GLASS BREAKAGE MICROPHONE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HATCH LATCH SWITCH
HATCHBACK
HOOD SWITCH (OPTIONAL)
HOT AT ALL TIMES
IGNITION KEY SWITCH
IGNITION SWITCH
INTEGRATED CONTROL UNIT
J/C (LEFT KICK PANEL)
J/C 417 (LEFT KICK PANEL)
LEFT REAR DOOR SWITCH
LEFT TAILGATE LATCH SWITCH
LIGHT FLASHER RELAY (ABOVE LEFT KICK PANEL)
LIGHT FUSE 40
LOCK
LT GREN/
LT GRN/RED WIRE
NCA WIRE
OPTION FUSE 36
ORG/ WIRE
RED WIRE
RED/GRN WIRE
RIGHT REAR DOOR SWITCH
RIGHT TAILGATE LATCH SWITCH
SECURITY CONTROL UNIT (UNDERSIDE OF DRIVER'S SEAT)
SECURITY IN- LINE FUSE HOLDER (ABOVE LEFT KICK PANEL)
SECURITY INDICATOR
SIREN (OPTIONAL)
SRS FUSE BLOCK
STARTING/CHARGING SYSTEM HORNS SYSTEM
TRUNK LATCH SWITCH
UNDER- DASH FUSE/ RELAY BOX FUSE 14
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WARNING SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit -> HATCH LATCH SWITCH
Wiring diagram hatch latch switch (2 of 2)
ANTI-THEFT SYSTEM (OPTIONAL)
CARGO AREA LIGHT
CEILING LIGHT
DOOR ON
DRIVER'S DOOR SWITCH
FUSE 3
GRN WIRE
GRN/BLU WIRE
HATCH LATCH SWITCH
HATCHBACK SEDAN/COUPE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INTEGRATED CONTROL UNIT
LEFT REAR DOOR SWITCH
LEFT TAILGATE LATCH SWITCH
LT GRN/RED WIRE
OFF
PASS- ENGER'S DOOR SWITCH
RIGHT REAR DOOR SWITCH
RIGHT TAILGATE LATCH SWITCH
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX
WHT/RED WIRE
Go to component -> Interior light circuit (2 of 2) -> HATCH LATCH SWITCH
