Car Wiring Diagrams for Wiper/washer circuit, except hybrid without keyless access for Honda Civic IX facelift (2013-2016)

B-CAN TRANSCEIVER B- B- CAN L CAN H BLK WIRE BLK/ BLU WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECM/PCM (LEFT SIDE OF ENGINE COMPT) FUSE 28 FUSE 46 FUSE 5 GAUGE CONTROL MODULE (TACH) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START INDICATOR DRIVE CIRCUIT INTERMITTENT DWELL TIME CONTROLLER MAIN CIRCUIT MICU MIST OFF ORG/ WIRE PARK PNK WIRE PPL RED WIRE RESERVOIR) RUN WIRE SWITCH (A/T) (REAR OF TRANSMISSION HOUSING) TRANSMISSION RANGE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WASH SWITCH WASHER FLUID LEVEL IND WASHER FLUID LEVEL SWITCH (CANADA) (IN WASHER FLUID RESERVOIR TANK) WHT WIRE WINDOW WASHER MOTOR (IN WASHER FLUID WINDSHIELD WASHER WINDSHIELD WASHER MOTOR RELAY WINDSHIELD WIPER HIGH/LOW RELAY WINDSHIELD WIPER INTERMITTENT RELAY WINDSHIELD WIPER MOTOR (UNDER RIGHT SIDE OF COWL COVER) WINDSHIELD WIPER SWITCH WIPER/ WASHER SWITCH YEL WIRE
