Trunk release circuit, hybrid for Honda Civic IX facelift (2013-2016)
Trunk release circuit, hybrid
B-CAN
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FUSE 41
FUSE 5
GAUGE CONTROL MODULE (TACH)
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE FUSE 22
HOT IN ON OR START
INDICATOR
KEYLESS ACCESS CONTROL UNIT
LT BLU WIRE
MAIN CIRCUIT
MICU
OF ENGINE COMPT)
PNK WIRE
RED WIRE
TAILGATE ACTUATOR RELAY
TRUNK IND
TRUNK LID OPENER LOCK SWITCH
TRUNK LID OUTER HANDLE SWITCH
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
WHT WIRE
