Honda Civic IX facelift (2013-2016) Supplemental restraints circuit, hybrid

BLK WIRE BLU WIRE BRN WIRE CABLE REEL (TOP OF STEERING COLUMN) CENTER JUNCTION BOX 1 COMPUTER DATA LINES SYSTEM DRIVER AIR BAG INFLATOR (IN STEERING WHEEL) FRONT PASSENGER AIR BAG INFLATOR (RIGHT SIDE OF DASH) FUSE 29 FUSE 3 GRN WIRE HOT IN ON OR START LEFT FRONT IMPACT SENSOR (BEHIND LEFT END OF FRONT BUMPER) LT BLU WIRE LT GRN WIRE PPL RED WIRE RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT END OF FRONT BUMPER) SRS UNIT (UNDER FRONT OF CENTER CONSOLE) UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR FRONT PASSENGER'S WEIGHT SENSOR UNIT GRN WIRE GRY WIRE LT GRN WIRE RED WIRE WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM F-CAN H F-CAN TRANSCEIVER F-CAN L FAIL SAFE CIRCUIT FORCED TURNING ON CIRCUIT FUSE 23 FUSE 5 GAUGE CONTROL MODULE (TACH) GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INDICATOR DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE MAIN CIRCUIT MICU PPL RED WIRE REGULATOR RIGHT SIDE IMPACT SENSOR (FIRST) (BASE OF RIGHT "B" PILLAR) RIGHT SIDE IMPACT SENSOR (SECOND) (BASE OF RIGHT "C" PILLAR) SEAT BELT REMINDER IND SIDE AIR BAG CUT-OFF IND SRS IND UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE DRIVER'S SEAT BELT OUTER LAP TENSIONER DRIVER'S SEAT POSITION SENSOR (UNDER LEFT REAR OF DRIVER'S SEAT) GRN WIRE GRY WIRE LEFT SIDE IMPACT SENSOR (FIRST) (BASE OF LEFT "B" PILLAR) LEFT SIDE IMPACT SENSOR (SECOND) (BASE OF LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE YEL WIRE
