Supplemental restraints circuit, except hybrid sedan for Honda Civic IX facelift (2013-2016)

Supplemental restraints circuit, except hybrid sedan (1 of 4)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid sedan (1 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE CABLE REEL (ON STEERING COLUMN) CENTER JUNCTION BOX 1 COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG INFLATOR (IN STEERING WHEEL) FRONT PASSENGER'S AIR BAG INFLATOR (BEHIND RIGHT SIDE OF DASH) FUSE 29 FUSE 3 GRN WIRE HOT IN ON OR START LEFT FRONT IMPACT SENSOR (BEHIND LEFT END OF FRONT BUMPER) LT BLU WIRE LT GRN WIRE PPL RED WIRE RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT END OF FRONT BUMPER) SRS UNIT (UNDER FRONT OF CENTER CONSOLE) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid sedan (2 of 4)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid sedan (2 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER'S WEIGHT SENSOR UNIT GRN WIRE GRY WIRE LT GRN WIRE RED WIRE WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid sedan (3 of 4)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid sedan (3 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L F-CAN TRANSCEIVER FAIL SAFE CIRCUIT FORCED TURNING ON CIRCUIT FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR FUSE 5 GAUGE CONTROL MODULE (TACH) GRY WIRE HOT IN ON OR START INDICATOR DRIVE CIRCUIT LT GRN WIRE MAIN CIRCUIT PPL RED WIRE RIGHT SIDE IMPACT SENSOR (FIRST) (BASE OF RIGHT "B" PILLAR) RIGHT SIDE IMPACT SENSOR (SECOND) (IN RIGHT "C" PILLAR) SEAT BELT REMINDER IND SIDE AIR BAG CUT-OFF IND SRS IND UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid sedan (4 of 4)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid sedan (4 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT POSITION SENSOR (UNDER LEFT REAR OF DRIVER'S SEAT) DRIVER'S SEAT BELT OUTER LAP TENSIONER GRN WIRE GRY WIRE LEFT SIDE IMPACT SENSOR (FIRST) (BASE OF LEFT "B" PILLAR) LEFT SIDE IMPACT SENSOR (SECOND) (IN LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE SELECTABLE ENERGY ABSORPTION DEVICE SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE YEL WIRE
