Supplemental restraints circuit, except hybrid coupe for Honda Civic IX facelift (2013-2016)

Supplemental restraints circuit, except hybrid coupe (1 of 3)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid coupe (1 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE CABLE REEL (ON STEERING COLUMN) CENTER JUNCTION BOX 1 COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG INFLATOR (IN STEERING WHEEL) FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR FRONT PASSENGER'S AIR BAG INFLATOR (BEHIND RIGHT SIDE OF DASH) FUSE 29 GRN WIRE GRY WIRE HOT IN ON OR START HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (UNDER LEFT FUSE 3 END OF DASH) LEFT FRONT IMPACT SENSOR (BEHIND LEFT END OF FRONT BUMPER) LT BLU WIRE LT GRN WIRE PPL RED WIRE RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT END OF FRONT BUMPER) SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid coupe (2 of 3)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid coupe (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L F-CAN TRANSCEIVER FAIL SAFE CIRCUIT FORCED TURNING ON CIRCUIT FRONT PASSENGER'S WEIGHT SENSOR UNIT FUSE 5 GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE HOT IN ON OR START INDICATOR DRIVE CIRCUIT MAIN CIRCUIT RED WIRE SEAT BELT REMINDER IND SIDE AIR BAG CUT-OFF IND SRS IND UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE YEL WIRE

Supplemental restraints circuit, except hybrid coupe (3 of 3)

Civic Honda IX facelift (2013-2016): Supplemental restraints circuit, except hybrid coupe (3 of 3)

Get access

7 1 CVT M/T BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT POSITION SENSOR (UNDER LEFT REAR OF DRIVER'S SEAT) GRN WIRE GRY WIRE LEFT SIDE IMPACT SENSOR (FIRST) (UNDER CENTER OF LEFT DOOR SILL) LEFT SIDE IMPACT SENSOR (SECOND) (NEAR BASE OF LEFT "B" PILLAR) LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT SIDE IMPACT SENSOR (FIRST) (UNDER CENTER OF RIGHT DOOR SILL) RIGHT SIDE IMPACT SENSOR (SECOND) (NEAR BASE OF RIGHT "B" PILLAR) SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE YEL WIRE
