Premium radio circuit, with navigation for Honda Civic IX facelift (2013-2016)
Premium radio circuit, with navigation (1 of 4)
11 12 PPL
AM/FM ANTENNA AMPLIFIER
AUDIO REMOTE MULTI-INFORMATION SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CH+ SWITCH
COMPUTER DATA LINES (UNDER SYSTEM FRONT PASSENGER'S SEAT)
COMPUTER DATA LINES SYSTEM
CONNECTOR
FUSE 19
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INFO
LT BLU WIRE
MENU
MICU
NAVIGATION SYSTEM
NCA WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK 1 2 3 4 5 6 7 8 WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
USB
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WINDOW ANTENNA (AM/FM)
YEL WIRE
Premium radio circuit, with navigation (2 of 4)
11 12 PPL
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR SPEAKER
GRN WIRE
GRY WIRE
HDMI PORT
LEFT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER'S DOOR SPEAKER PPL
PNK 1 2 3 4 5 6 7 8 WIRE
PNK 3 4 5 6 WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR SPEAKER
STEREO AMPLIFIER (LEFT SIDE OF DASH)
SUBWOOFER
WHT WIRE
YEL WIRE
Premium radio circuit, with navigation (3 of 4)
B-CAN B-CAN
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
FUSE
FUSE FUSE FUSE (LEFT SIDE OF ENGINE COMPT)
GAUGE CONTROL MODULE (TACH)
GRY WIRE
HFL/HFL- NAVIGATION VOICE CONTROL SWITCH
HOT AT ALL TIMES
KEYLESS ACCESS CONTROL UNIT
LT GRN WIRE
MAIN CIRCUIT
NAVI BACK
NAVI TALK (IN STEERING WHEEL)
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK 3 4 5 6 WIRE
PNK WIRE
PPL
RED WIRE
RELAY 1 ENERGIZED
RIGHT TWEETER
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
XM ANTENNA SIGNAL ANTENNA
Premium radio circuit, with navigation (4 of 4)
