Base radio circuit, except hybrid sedan for Honda Civic IX facelift (2013-2016)

Base radio circuit, except hybrid sedan (1 of 4)

Civic Honda IX facelift (2013-2016): Base radio circuit, except hybrid sedan (1 of 4)

Get access

AM/FM ANTENNA AMPLIFIER AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 1 CENTER JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM CONNECTOR FRONT PASSENGER'S DOOR SPEAKER FUSE (LEFT SIDE OF ENGINE COMPT) FUSE 19 FUSE 5 GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START LT BLU WIRE LT GRN WIRE MICU NCA WIRE ORG/ WIRE PNK WIRE PPL RIGHT TWEETER UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX USB WHT WIRE WINDOW ANTENNA (AM/FM) YEL WIRE

Base radio circuit, except hybrid sedan (2 of 4)

Civic Honda IX facelift (2013-2016): Base radio circuit, except hybrid sedan (2 of 4)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 1 CENTER JUNCTION BOX 2 DRIVER'S DOOR SPEAKER GRN WIRE GRY WIRE KEYLESS ACCESS CONTROL UNIT LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER WHT WIRE YEL WIRE

Base radio circuit, except hybrid sedan (3 of 4)

Civic Honda IX facelift (2013-2016): Base radio circuit, except hybrid sedan (3 of 4)

Get access

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (ON STEERING COLUMN) CH- COMPUTER DATA LINES SYSTEM F-CAN L F-CAN H F-CAN TRANSCEIVER GAUGE CONTROL MODULE (TACH) GRN WIRE GRY WIRE INFO LINES SYSTEM COMPUTER DATA LT GRN WIRE MAIN CIRCUIT MENU MULTI INFORMATION DISPLAY UNIT NCA WIRE ORG/ WIRE PNK WIRE RED WIRE SOURCE VOL DOWN VOL UP WHT WIRE YEL WIRE

Base radio circuit, except hybrid sedan (4 of 4)

Civic Honda IX facelift (2013-2016): Base radio circuit, except hybrid sedan (4 of 4)

Get access

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HDMI PORT LANE WATCH CAMERA LANE WATCH SWITCH NAVIGATION SYSTEM NCA WIRE RED WIRE RIGHT POWER MIRROR USB PORT C WHT WIRE YEL WIRE
