Power door locks circuit, hybrid for Honda Civic IX facelift (2013-2016)
Power door locks circuit, hybrid (1 of 6)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
DASH)
DOOR
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE
FUSE 32 FUSE 33
FUSE FUSE
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
HORNS SYSTEM HORNS SYSTEM
HOT AT ALL TIMES
J/C
KEY
KEY CYLINDER SWITCH DRIVER'S DOOR
KNOB
LOCK
LOCK RELAY
LT BLU WIRE
LT GRN WIRE
MICU
NEUTRAL
ORG/ WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
TAILGATE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
UNLOCK
UNLOCK RELAY
UNLOCK RELAY (DR)
WHT WIRE
YEL WIRE
Power door locks circuit, hybrid (2 of 6)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCK
DOOR LOCK KNOB
DRIVER'S DOOR SWITCH (ON DRIVER'S "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (ON FRONT PASSENGER'S "B" PILLAR)
GRN WIRE
GRY WIRE
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
LEFT REAR DOOR SWITCH (ON LEFT REAR "C" PILLAR)
LOCK
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
RIGHT REAR DOOR SWITCH (ON RIGHT REAR "C" PILLAR)
SEAT)
UNLOCK
WHT WIRE
YEL WIRE
Power door locks circuit, hybrid (3 of 6)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMPT)
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 11
FUSE 2-1
FUSE 23
FUSE FUSE FUSE OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE
KEYLESS ACCESS CONTROL UNIT (IF EQUIPPED)
LT BLU WIRE
LT GRN WIRE
MICU
MULTI INFORMATION DISPLAY UNIT
ORG/ WIRE
PNK COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
PPL
RED WIRE
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (LEFT END
WHT WIRE
YEL WIRE
Power door locks circuit, hybrid (4 of 6)
ACCRY RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE START/STOP SWITCH
FUSE 2-7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
UNDER-DASH SUB-RELAY BOX
WHT WIRE
YEL WIRE
Power door locks circuit, hybrid (5 of 6)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
B-CAN H B-CAN L
B-CAN TRANSCEIVER
BLINKING CIRCUIT
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR IND
GAUGE CONTROL MODULE
GAUGE CONTROL MODULE (SPEEDO)
GRN WIRE
GRY WIRE
IMMOBILIZER IND
INDICATOR DRIVE CIRCUIT
INDICATOR PANEL LIGHT (PARK PIN SWITCH: BASE OF A/T SHIFT LEVER)
KEYLESS ACCESS SYSTEM IND
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PARK PIN SWITCH/ A/T GEAR POSITION
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
SEAT)
SECURITY HOOD SWITCH (ON ENGINE COMPT HOOD LATCH ASSEMBLY)
SECURITY IND
TACH
WHT WIRE
YEL WIRE
Power door locks circuit, hybrid (6 of 6)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LF ANTENNA
DRIVER'S DOOR TOUCH SENSOR
FRONT INTERIOR LF ANTENNA
FRONT PASSENGER'S DOOR TOUCH SENSOR
GRN WIRE
GRY WIRE
KEYLESS ACCESS CONTROL UNIT (IF EQUIPPED)
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
SMART BUZZER
TOUCH SENSOR
TRUNK LID OUTER HANDLE SWITCH
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
