Courtesy lamps circuit, hybrid for Honda Civic IX facelift (2013-2016)
Courtesy lamps circuit, hybrid
BLK WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH (ON DRIVER'S "B" PILLAR)
FCW/LDW CAMERA UNIT (TOP CENTER OF WINDSHIELD)
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S DOOR SWITCH (ON FRONT PASSENGER'S "B" PILLAR)
FUSE
FUSE 41
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR DOOR SWITCH (ON LEFT REAR "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
MICU
OF LUGGAGE COMPT LID)
ON OFF DOOR PNK WIRE
PNK WIRE
RIGHT REAR DOOR SWITCH (ON RIGHT REAR "C" PILLAR)
TAILGATE ACTUATOR RELAY
TRUNK LIGHT
UNDER-DASH FUSE/ RELAY BOX (LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
