Courtesy lamps circuit, except hybrid for Honda Civic IX facelift (2013-2016)
Courtesy lamps circuit, except hybrid
BLK WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT
COMPUTER DATA LINES SYSTEM
DOOR LOCK KNOB
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR SWITCH (IN DRIVER "B" PILLAR)
EXCEPT 1.8L M/T
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGERS DOOR SWITCH (IN FRONT PASSENGER "B" PILLAR)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION KEY SWITCH
KEY
KEY IN
LEFT REAR DOOR SWITCH (SEDAN) (IN LEFT "C" PILLAR)
LOCK
LT BLU WIRE
LT GRN WIRE
MAP LIGHT
MICU
MOONROOF SWITCH/ INTERIOR LIGHT SWITCH (EXCEPT 1.8L M/T)
OFF
OFF ON
ON OFF DOOR PNK WIRE
PNK WIRE
RIGHT REAR DOOR SWITCH (SEDAN) (IN RIGHT "C" PILLAR)
SEDAN, COUPE
SWITCH/TRUNK RELEASE ACTUATOR
TRUNK LIGHT
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
UNLOCK
WHT WIRE
