Headlights circuit, except hybrid for Honda Civic IX facelift (2013-2016)

Headlights circuit, except hybrid (1 of 2)

Civic Honda IX facelift (2013-2016): Headlights circuit, except hybrid (1 of 2)

Get access

AUDIO UNIT/ AUDIO NAVIGATION UNIT B-CAN B-CAN B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRAKE LEVER) BRN WIRE CIRCUIT COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM DIMMER/ FLASH-TO- PASS SWITCH 0) LOW 1) HIGH 2) PASS DIMMING CIRCUIT DRL IND EXCEPT 1.8L COUPE M/T, CANADA COUPE FOG LIGHT SWITCH FRONT FOG LIGHTS IND FUSE GAUGE CONTROL MODULE (TACH) GRY WIRE HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD HIGH BEAM IND HOT IN ON OR START IGNITION KEY SWITCH INDICATOR DRIVE CIRCUIT KEYLESS ACCESS CONTROL UNIT LIGHTS ON IND LT BLU WIRE LT GRN WIRE MAIN CIRCUIT MICU OFF ORG/ WIRE PARKING BRAKE SWITCH (AT BASE OF PARKING PNK WIRE PPL RED WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE

Headlights circuit, except hybrid (2 of 2)

Civic Honda IX facelift (2013-2016): Headlights circuit, except hybrid (2 of 2)

Get access

1.8L COUPE M/T, CANADA COUPE AUTOMATIC LIGHTING/SUNLIGHT SENSOR (EXCEPT 1.8L M/T) (TOP CENTER OF DASH) BLK WIRE BLU WIRE CENTER JUNCTION BOX 1 CENTER JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM EXCEPT 1.8L COUPE M/T, CANADA COUPE FRONT FOG LIGHT RELAY FUSE FUSE 1-6 FUSE 12 FUSE 29 FUSE 20 FUSE FUSE GRN WIRE GRY WIRE HEADLIGHT LOW BEAM RELAY HOT AT ALL TIMES LEFT FOG LIGHT LEFT HEADLIGHT (HIGH) LEFT HEADLIGHT (LOW) LEFT HEADLIGHT LOW BEAM RELAY ORG/ WIRE PNK WIRE PPL RED WIRE RELAY CONTROL MODULE RIGHT FOG LIGHT RIGHT HEADLIGHT (HIGH) RIGHT HEADLIGHT (LOW) RIGHT HEADLIGHT LOW BEAM RELAY UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE
