Honda Civic IX facelift (2013-2016) w/o keyless access Wiring diagrams
This page contains all the electrical diagrams for the component. w/o keyless access, in which he is found in the car Honda Civic IX facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o keyless access (1 of 2)
1.8L
15 16 17 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
D/L DR UNLOCK RELAY
D/L LOCK RELAY
D/L UNLOCK RELAY
DOOR
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE
FUSE 32 FUSE 33
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HORNS SYSTEM
HORNS SYSTEM COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES
IGNITION KEY SWITCH
KEY
KEY CYLINDER SWITCH DRIVER'S DOOR
KNOB
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NEUTRAL
ORG/ WIRE
PASSENGER'S SEAT)
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RELAY
RIGHT END OF DASH)
TRUNK RELEASE ACTUATOR
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNLOCK
W/ KEYLESS ACCESS
W/O KEYLESS ACCESS
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, except hybrid (1 of 6) -> W/O KEYLESS ACCESS
