Honda Civic IX facelift (2013-2016) volume up switch Wiring diagrams
This page contains all the electrical diagrams for the component. volume up switch, in which he is found in the car Honda Civic IX facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram volume up switch (1 of 7)
15 16 17 PNK WIRE
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CENTER JUNCTION BOX 2
CH+ SWITCH
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
INFO SWITCH
MENU SWITCH
MULTI INFORMATION DISPLAY UNIT
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
SOURCE SWITCH
USB PORT B 5 PIN CONNECTOR
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Base radio circuit, except hybrid coupe (2 of 3) -> VOLUME UP SWITCH
Wiring diagram volume up switch (2 of 7)
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CHANNEL
COMBINATION LIGHT SWITCH
GRY WIRE
INFO SWITCH
MENU SWITCH
NCA WIRE
PNK 6 7 8 WIRE
PNK WIRE
PPL
PPL 11 12
RED WIRE
SOURCE SWITCH
SWITCH
USB PORT C
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Base radio circuit, hybrid (4 of 5) -> VOLUME UP SWITCH
Wiring diagram volume up switch (3 of 7)
11 12 13 14 15 PNK WIRE
22 21 23 PNK WIRE
3 2 PNK WIRE
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (EXCEPT HYBRID: ON STEERING WHEEL)
CENTER JUNCTION BOX 2
CHANNEL CHANNEL
COMPUTER DATA LINES SYSTEM
END OF DASH) (HYBRID: LEFT END OF DASH)
FUSE
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (RIGHT SIDE OF DASH)
HFL/HFL- NAVIGATION VOICE CONTROL SWITCH
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
MENU SWITCH INFO SWITCH
MICROPHONE (EXCEPT HYBRID: IN ROOF CONSOLE) (HYBRID: CENTER FRONT OF ROOF)
MICU
NAVI NAVI TALK BACK
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
SWITCH SWITCH
UNDER-DASH FUSE/RELAY BOX (EXCEPT HYBRID: UNDER LEFT
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Hands free module circuit (1 of 2) -> VOLUME UP SWITCH
Wiring diagram volume up switch (4 of 7)
11 12 PPL
AM/FM ANTENNA AMPLIFIER
AUDIO REMOTE MULTI-INFORMATION SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CH+ SWITCH
COMPUTER DATA LINES (UNDER SYSTEM FRONT PASSENGER'S SEAT)
COMPUTER DATA LINES SYSTEM
CONNECTOR
FUSE 19
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INFO
LT BLU WIRE
MENU
MICU
NAVIGATION SYSTEM
NCA WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK 1 2 3 4 5 6 7 8 WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
USB
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WINDOW ANTENNA (AM/FM)
YEL WIRE
Go to component -> Navigation circuit, except hybrid (1 of 4) -> VOLUME UP SWITCH
Wiring diagram volume up switch (5 of 7)
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CHANNEL
COMBINATION LIGHT SWITCH
GRY WIRE
INFO SWITCH
MENU SWITCH
NCA WIRE
PNK 6 7 8 WIRE
PNK WIRE
PPL
PPL 11 12
RED WIRE
SOURCE SWITCH
SWITCH
USB PORT C
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, hybrid (4 of 5) -> VOLUME UP SWITCH
Wiring diagram volume up switch (6 of 7)
11 12 PPL
AM/FM ANTENNA AMPLIFIER
AUDIO REMOTE MULTI-INFORMATION SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CH+ SWITCH
COMPUTER DATA LINES (UNDER SYSTEM FRONT PASSENGER'S SEAT)
COMPUTER DATA LINES SYSTEM
CONNECTOR
FUSE 19
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INFO
LT BLU WIRE
MENU
MICU
NAVIGATION SYSTEM
NCA WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK 1 2 3 4 5 6 7 8 WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
USB
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WINDOW ANTENNA (AM/FM)
YEL WIRE
Go to component -> Premium radio circuit, with navigation (1 of 4) -> VOLUME UP SWITCH
Wiring diagram volume up switch (7 of 7)
11 12 PPL
AM/FM ANTENNA AMPLIFIER
AUDIO REMOTE MULTI-INFORMATION SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CH+ SWITCH CH- SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTOR
FUSE 19
FUSE 29 FUSE 19
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INFO
LT BLU WIRE
MENU
MICU
NAVIGATION SYSTEM
NCA WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
UNDER- HOOD FUSE/ RELAY BOX (LEFT SIDE OF ENGINE COMPT)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
USB
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WINDOW ANTENNA (AM/FM)
YEL WIRE
Go to component -> Premium radio circuit, without navigation (1 of 3) -> VOLUME UP SWITCH
