Honda Civic IX facelift (2013-2016) (upper left center Wiring diagram
This page shows the only wiring diagram for the component.(upper left center, which is found in the car Honda Civic IX facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (upper left center (1 of 1)
BATTERY
BATTERY SENSOR
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIODE F (IN UNDER-HOOD FUSE/RELAY BOX)
ENGINE START/STOP
FUSE
FUSE 1-6
FUSE 2-5
FUSE 31
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INHIBITOR RELAY
KEYLESS ACCESS CONTROL UNIT
LT BLU WIRE
MAGNETIC SWITCH
MICU
OF DASH)
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
RED WIRE
STARTER
STARTER CUT RELAY 1
STARTER CUT RELAY 2
SWITCH
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 1.5l hybrid, starting circuit -> (UPPER LEFT CENTER
