Honda Civic IX facelift (2013-2016) rearview camera Wiring diagrams
This page contains all the electrical diagrams for the component. rearview camera, in which he is found in the car Honda Civic IX facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rearview camera (1 of 2)
Go to component -> Rear camera circuit, except hybrid with multi-information display -> REARVIEW CAMERA
Wiring diagram rearview camera (2 of 2)
Go to component -> Rear camera circuit, except hybrid without multi-information display -> REARVIEW CAMERA
