Honda Civic IX facelift (2013-2016) menu switch info switch Wiring diagram
This page shows the only wiring diagram for the component.menu switch info switch, which is found in the car Honda Civic IX facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram menu switch info switch (1 of 1)
11 12 13 14 15 PNK WIRE
22 21 23 PNK WIRE
3 2 PNK WIRE
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (EXCEPT HYBRID: ON STEERING WHEEL)
CENTER JUNCTION BOX 2
CHANNEL CHANNEL
COMPUTER DATA LINES SYSTEM
END OF DASH) (HYBRID: LEFT END OF DASH)
FUSE
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (RIGHT SIDE OF DASH)
HFL/HFL- NAVIGATION VOICE CONTROL SWITCH
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
MENU SWITCH INFO SWITCH
MICROPHONE (EXCEPT HYBRID: IN ROOF CONSOLE) (HYBRID: CENTER FRONT OF ROOF)
MICU
NAVI NAVI TALK BACK
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
SWITCH SWITCH
UNDER-DASH FUSE/RELAY BOX (EXCEPT HYBRID: UNDER LEFT
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Hands free module circuit (1 of 2) -> MENU SWITCH INFO SWITCH
